Pipe Measurement Requirements
In order to improve the quality of product processing, product development and production speed, the measurement of automotive piping parts, throughout the entire process of automotive manufacturing and processing. Common bending pipe parts testing projects include: bending intersection (XYZ), bending cut point, bending processing parameters (YBC/LRA), bending diameter, bending length, bending unfolding, A-END/B-END end point coordinates and distance, springback extension parameters.
For different production processes, the pipeline measurement needs are different. Such as in the pipe design stage, the need to reverse measurement, improve product development speed; in the first trial production stage, the need for measurement, adjust the processing parameters of the bend; in the mass production stage, you need to improve the detection efficiency, to ensure the accuracy of detection.
However, whether it is the traditional manual scribing measurement, or the use of three coordinates for automatic measurement, can not provide satisfactory integrated measurement solutions, users need comprehensive functions, outstanding performance, more targeted professional pipe bending measurement solutions.
